Deep Cycle Low Temperature LiFePO4 Lithium Battery 12V 100AH with Heating System and Bluetooth
Introduction:
The Low Temperature LiFePO4 Battery is specially designed with a heating film on the BMS, when the temperature is below 32°F (0°C), the heating film will be turned on under charging conditions. During the heating process, the charger only supplies power upon the heating film and it will not charge the battery when the temperature is lower than 0°C. When heated to 50°F (10°C), the BMS stops heating and the battery starts to charge. In the process of storage and discharge, the heating film neither works nor consumes battery power.
The ultra-light Deep Cycle LiFePO4 battery can be used as a pure supply battery and can be loaded up to 200A continuously and 600A Pulse for a short time. The significantly lower weight, the long operational reliability, the long cycle life and the long service life are decisive advantages over conventional batteries of old technology.
Specification:
Electrical Characteristics |
Nominal Voltage |
12.8V |
Nominal Capacity |
100Ah |
|
Minimum Capacity |
100Ah |
|
Energy |
1280Wh |
|
Cycle Life |
>5000 cycles |
|
Months Self Discharge |
<3% |
|
Efficiency of Charge |
100% @0.5C |
|
Efficiency of Discharge |
96~99% @0.5C |
|
BMS Functions |
Over charge, over discharge, over current, short circuit and temperature protection |
|
Standard Charge |
Charge Voltage |
14.2-14.6V |
Charge Mode |
0.2C to 14.6V, then 14.6V,charge current to 0.02C (CC/CV) |
|
Charge Current |
20A |
|
Max. Charge Current |
50A |
|
Standard Discharge |
Max Continuous Discharge Current |
100A |
Peak Discharge Current |
400A±40A 0.5-1.5S |
|
Discharge Cut-off Voltage |
10V±0.5V |
|
Environmental |
Charge Temperature |
0 ℃ to 55 ℃ (32F to 131F) @60±25% Relative Humidity |
Discharge Temperature |
-20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity |
|
Storage Temperature |
-20 ℃ to 45 ℃ (-4F to 113F) @60±25% Relative Humidity |
|
IP Class |
IP65 |
|
Mechanical |
Plastic Case |
ABS |
Approx. Dimensions |
L280Xw177xH188mm |
|
Approx. Weight |
11kgs |
|
Heating Element Specifications |
Heating Temperature Range |
-4 to 50 ºF (-20 to 10 ℃) |
Heating Time (Approximately) |
1 hr @ 5 A |
|
BMS Heating Element Cut-Off |
167 ºF (75 ℃) |
Remarks:
1. Warranty: 5 Years
2. OEM/ODM accepted, can supply sample(s) for test
3. Factory supplied directly, accept small qty order
4. Capable with various shipping methods, by air, by sea, by train, with FOB, CIF, DDP or DDU service
Applications:
Solar/Wind Energy Storage Application
Back-up Power for UPS/ EPS
Low Speed Electric Vehicles, i.e. RV, Caravan, Motor home
Marine/fishing Boats
Telecommunication
DC Power Supply
Auto Control System
Power Tools
Electric Toys
Features of Our LiFePO4 Battery:
• High current resistant
• Perfect replacement to lead battery
• Built-in BMS
• Very light weight
• Fast charging
• High intrinsic safety
• Can be used in all positions
• Wide Temperature: -20 ℃ to 60 ℃ (-4F to 140F)
• Over 5000 cycles at 90% discharge
• Lifespan up to 10 years
• 100% maintenance free
• Environmentally friendly, no lead, no acid
• Recyclable
Optional Function on Our LiFePO4 Batteries:
Bluetooth APP
We can customize the bluetooth APP with your company Logo and unique design for you.
Users can monitor the real-time status through the Bluetooth APP on the smart mobile phones.
