Portable Power Station 1280Wh Lifepo4 24V 50Ah

Electrical Characteristics

Nominal Voltage

25.6V

Nominal Capacity

50Ah

Minimum Capacity

50Ah

Energy

1280Wh

Cycle Life

>2000 cycles @ 100%DOD

>4000 cycles @ 80%DOD

Months Self Discharge

<3%

Efficiency of Charge

100% @0.5C

Efficiency of Discharge

96~99% @0.5C

BMS Functions

Over charge, over discharge, over current, short circuit and temperature protection

Standard Charge & Discharge

Charge Voltage

28.8-29.2V

Charge Mode

0.2C to 29.2V, then 29.2V,charge current to 0.02C (CC/CV)

Charge Current

5A

Max. Charge Current

10A   300W Max

Max Continuous Discharge Current

50A

Peak Discharge Current

100A  1-3S

Discharge Cut-off Voltage

20V±0.5V

Inverter Input & Output

AC Input  Voltage

220 VAC 50HZ & 110 VAC 60HZ

AC Power

1200W

AC peak Power

2400W

Highest conversion rate

93%

Solar panel power

450W

Solar Standard Charging current

10A

Solar charging current

20A Max

Open circuit voltage

30-45V DC，Max450W DC

Solar Charge

Fill Continuously

Waveform

Pure sine wave

DC Output

USB-2    USB-3

5V 2.1A

USB-1    USB-4

5V/9V/12V  18W Max

Type-C  *2

5V/9V/12V  30W*2  Max

DC5.5*2.5

12V 7A Max

Mechanical

Shell material

ABS+ Aluminum alloy

Approx. Dimensions

L368xW200xH275mm

Approx. Weight

14.3kgs

Environmental

Charge Temperature

0 ℃ to 55 ℃ (32F to 131F) @60±25% Relative Humidity

Discharge Temperature

-20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity

Storage Temperature

0 ℃ to 45 ℃ (32F to 113F) @60±25% Relative Humidity

IP Class

IP20
