Specifications:
| Model | LiFePO4 Battery 24V 50AH |
| Nominal Voltage | 25.6V |
| Nominal Capacity | 50Ah |
| Energy | 1280Wh |
| Cycle Life | >5000 cycles |
| Months Self Discharge | <3% |
| Efficiency of Charge | 100% @0.5C |
| Efficiency of Discharge | 96~99% @0.5C |
| BMS Functions | Over charge, over discharge, over current, short circuit and temperature protection |
| Charge Voltage | 28.4-29.2V |
| Charge Mode | 0.2C to 29.2V, then 29.2V,charge current to 0.02C (CC/CV) |
| Charge Current | 4A |
| Max. Charge Current | 50A |
| Max Continuous Discharge Current | 50A |
| Peak Discharge Current | 150A 1-3S |
| Discharge Cut-off Voltage | 20V±0.5V |
| Charge Temperature | 0 ℃ to 55 ℃ (32F to 131F) @60±25% Relative Humidity |
| Discharge Temperature | -20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity |
| Storage Temperature | -20 ℃ to 45 ℃ (-4F to 113F) @60±25% Relative Humidity |
| IP Class | IP65 |
| Housing | ABS Plastic Case |
| Approx. Dimensions | 329x172x214mm (12.95''x6.77''x8.43'') |
| Approx. Weight | 11kgs (24.25lbs) |



Applications:
* Solar/Wind Energy Storage Applications
* Back-up Power for UPS/ EPS
* RV, Caravan, Motor home
* Marine/ Yacht/ Fishing Boats
* Telecommunication/ Data Center Base
* DC Power Supply
* Auto Control System
* Power Tools
* Electric Toys
