Welcome: HiPOWER BATTERY TECHNOLOGY
3840Wh All In One System with 3KVA Inverter LiFeP04 24V 150Ah
Introduction:
All-In-One Energy Storage System is a removable residential solar storage battery bank which can be operated under off grid. There is an inverter and PV systems built inside to form an Energy Storage System (short for ESS). The main functions are to store power generated by PV and power your home appliances. Our Energy Storage System can provide backup power for household during blackouts, reduce electricity bill and protect environment by consumption of solar energy.
Specification:
|
Electrical Characteristics |
|
|
Nominal Voltage |
25.6V |
|
Nominal Capacity |
150Ah |
|
Minimum Capacity |
150Ah |
|
Energy |
3840Wh |
|
Cycle Life |
>6000 cycles |
|
Months Self Discharge |
<3% |
|
Efficiency of Charge |
100% @0.5C |
|
Efficiency of Discharge |
96~99% @0.5C |
|
BMS Functions |
Over charge, over discharge, over current, short circuit and temperature protection |
|
Max. Modules in parallel |
1pcs |
|
Standard Charge and Discharge |
|
|
Charge Voltage |
28.4-29.2V |
|
Charge Mode |
0.2C to 29.2V, then 29.2V, charge current to 0.02C (CC/CV) |
|
Charge Current |
20A |
|
Max. Charge Current |
100A |
|
Max Continuous Discharge Current |
120A |
|
Peak Discharge Current |
300±50 A 1-3S |
|
Discharge Cut-off Voltage |
20V±0.5V |
|
Inverter |
|
|
Input Voltage |
90~280 VAC 50Hz/60Hz (Automatic adaptation) |
|
Inverter power |
6000VA Max |
|
Highest conversion rate |
93% |
|
Waveform |
Pure sine wave |
|
Solar panel power |
1500W |
|
Solar charging current |
50A |
|
Max Charging current |
20A |
|
Open circuit voltage |
30-32 VDC |
|
Solar Charge |
Built-in MPPT |
|
Mechanical |
|
|
Shell Material |
SPCC |
|
Approx. Dimensions |
L630Xw330xH470（H1 546）mm |
|
Approx. Weight |
63kgs |
|
Terminal Type |
Terminal 100A |
|
Environmental |
|
|
Charge Temperature |
0 ℃ to 55 ℃ (32F to 131F) @60±25% Relative Humidity |
|
Discharge Temperature |
-20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity |
|
Storage Temperature |
-20 ℃ to 45 ℃ (-4F to 113F) @60±25% Relative Humidity |
|
IP Class |
IP20 |
Features:
* Long Service Life: up to 10 years
* Proven Safety: Intelligent BMS and lithium iron phosphate cells ensure system with highest safety
* Easy Operation: The compact design allows easier and faster operation
* Low noise: Self-cooling with low noise.
Applications:
*Residential & Commercial Solar Energy Storage
*Solar/Wind Energy Storage
*Back-up Power Supply for UPS/ EPS
*Marine Boats/RV
Product Pictures:
